Magnetic stirrers with hot plate

Magnetic stirrers with hot plate Specification

Equipment Materials
mild steel

Power
220 Watt (w)

Voltage
220 Watt (w)

Material
mild steel and SS

Application
LAB

Warranty
1

Magnetic stirrers with hot plate Trade Information

Minimum Order Quantity
1 Piece

FOB Port
ambala

Payment Terms
Telegraphic Transfer (T/T)

Supply Ability
1 Piece Per Day

Delivery Time
15 Days

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
standard packing

Main Export Market(s)
Africa

Main Domestic Market
All India

Certifications
iso ce

About Magnetic stirrers with hot plate

Magnetic Stirrer

Specification

Highly polished SS top plate for optimum heat transfer.
Accurate steeples speed control maintains speed stability.
High magnetic adhesion.
Bushing according to DIN 12878 for connecting a contact thermometer.
Digital LED display for temp. & RPM available providing high accuracy.
PMDC motor for higher torque ever at low speeds.

Heating temperature range	Ambient -350 deg
Speed range	50 - 1500 RPM
Heating plate Material	Polished stainless steel
Motor rating	9/4W
Heat output	450W
Stirrer bar length max. output	80 mm
Dimensions of hot plate body	180 x 180
Weight of the body	2.9 kgs
Permissible ambient temperature	5 - 40 deg
Voltage	220 - 230 V
Frequency	50/60 Hz

Available models

Model No	Capacity
S.S.101	Magnetic stirrer with Hot plate for beakers up to 2 liter
S.S.102	Magnetic stirrer without Hot plate for beakers up to 2 liter
S.S.103	Magnetic stirrer with Hot plate for beakers up to 5 liter
S.S.104	Magnetic stirrer with Hot plate for beakers up to 5 liter
S.S.105	Magnetic stirrer with digital temp. & RPM indicator.

Precision and Efficiency for Laboratories

Designed specifically for laboratory environments, this magnetic stirrer with a hot plate offers precise control over both mixing and heating processes. The use of high-quality mild steel and stainless steel materials enhances durability, while the 220 Watt power rating delivers consistent, efficient results during sample preparation and chemical reactions.

Versatility and Robust Construction

With a combination of mild steel and stainless steel, this stirrer withstands rigorous daily use and exposure to diverse chemicals. Its robust design makes it an ideal investment for research institutions, quality control labs, and industrial applications requiring reliable, uninterrupted operation.

FAQs of Magnetic stirrers with hot plate:

Q: How does the magnetic stirrer with hot plate operate in a laboratory setting?

A: The device uses a rotating magnetic field to stir liquid samples, while the integrated hot plate heats the mixture as needed. This dual functionality allows for thorough and uniform mixing during chemical reactions, solution preparation, or other laboratory processes.

Q: What materials are used in the construction of this equipment, and why?

A: The magnetic stirrer with hot plate is made from mild steel and stainless steel, chosen for their durability, corrosion resistance, and ease of cleaning. These materials ensure longevity and consistent performance in demanding laboratory environments.

Q: When should I use a magnetic stirrer with a hot plate in my research or lab work?

A: This equipment is ideal when your experimental procedures require simultaneous stirring and controlled heating of liquids, such as in chemical synthesis, titration, or sample dissolution, improving reproducibility and safety.

Q: Where can I purchase the magnetic stirrer with hot plate in India?

A: You can purchase this equipment from authorized distributors, exporters, manufacturers, suppliers, traders, and wholesalers across India, making it widely accessible for labs nationwide.

Q: What is the process for maintaining this laboratory stirrer to ensure its longevity?

A: To maintain optimal performance, regularly clean the surface and the stirring bar, ensure the hot plate is clear of residues, and follow the manufacturers guidelines for periodic checks. Routine maintenance enhances safety and equipment life.

Q: How does using this equipment benefit my laboratory operations?

A: Utilizing a magnetic stirrer with hot plate increases efficiency, promotes uniform sample mixing, and enhances experimental accuracy. Its robust construction and warranty provide reliability and peace of mind for continuous lab use.
