Medical Microscope

Price 2700.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Medical Microscope Specification

View Head
Monocular head

Spare Parts
Replacement bulbs, eyepieces, objectives

Features
Sturdy metal body, anti-fungal coated optics, student friendly, robust design

Focus System
Coaxial coarse and fine adjustment

Theory
Stereo Microscope

Drawtube
Monocular, inclined at 45

Focal Distance
Approximately 50-70 mm

Magnification
40X, 100X, 400X (Three magnification settings)

Dimensions
Approx. 220 mm x 140 mm x 320 mm

Focus Range
Coarse and fine focusing system

Eyepieces
WF10X paired

Eyepiece Tube
Monocular, fixed

Illumination
Mirror illumination, sub-stage

Coarse Adjustment Range
20 mm approx.

Fine Adjustment Range
0.002 mm per graduation

Working Stage
Rectangular, with clips

Interpupillary Distance
Adjustable (50-75 mm)

Objective Achromatic
Achromatic objectives (4X, 10X, 40X)

Condenser
Fixed condenser with disc diaphragm

Light Source
Mirror, plane/concave (can be replaced by LED illuminator)

Medical Microscope Trade Information

Minimum Order Quantity
1 Piece

FOB Port
EXW

Supply Ability
1 Piece Per Day

Delivery Time
15 Days

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
standard packing

Main Domestic Market
All India

Certifications
iso ce

About Medical Microscope

Medical Microscope

Specification

We are listed amidst the most eminent manufacturers, suppliers and exporters of supreme quality Medical Microscope. Offered microscopes are widely used in many hospitals, clinics, medical institutions and educational institutions. These microscopes are available in different specifications. Medical Microscope is made in strict adherence with the international standards. Customers can avail these microscopes from us as per their needs and demands. Moreover, these are packed in styrofaom packing.

Other Information:

Widely used in Pathological labs and Educational institutes.
Separate Coarse & graduated Fine Motion with sensitivity of 0.002 mm.
Pressure Die-Cast interchangeable components with robust & sturdy construction.
Sub stage Abbe Condenser with Iris Diaphragm & filter holder, focussable with rack & pinion.
Illumination by Plano-concave reflector of dia 50 mm. (Interchangeable for electric illuminator 220 V- 15 W directly workable on mains)
Fitted with attachable graduated Mechanical Stage having X and Y movements.
Optical combination :-

Other Details

Eye Piece :-Coated WF 10X & Huy 5X
Objective :- A chromatic 10x , 40x/45x (SL) & 100x (SL) Oil Immersion.
Scratch proof highly resistant epoxy finish / powder coated.
Packed in Styrofoam packing inside a Sunmica clad Plywood box.
Dust Cover, cleaning cloth & lens cleaning paper.

Specification

Brand	standard steel
Portable	Yes
Model	BN01
Magnification	40x
Color	White

Advanced Stage Precision

The XY movement stage enables accurate navigation across samples, essential for detailed observation and documentation. The adjustable travel range (50 mm x 30 mm) promotes flexibility for different slide sizes and study requirements, making it suitable for diverse laboratory tasks and research applications.

User-Friendly Design and Optics

With a sturdy metal body, anti-fungal optical coating, and a comfortable inclined monocular head, this microscope is ideal for students and professionals alike. Coarse and fine adjustments simplify focus control, while the adjustable interpupillary distance accommodates various users, ensuring repetitive use does not cause strain.

Flexible Illumination Solutions

The microscope employs a mirror for illumination, which can be replaced by an LED illuminator for convenience. Its fixed condenser and disc diaphragm assist in managing light conditions for optimal viewing, even in settings with limited electrical infrastructure. The external light option supports fieldwork and portability.

FAQs of Medical Microscope:

Q: How do I adjust the stage movement on this medical microscope?

A: The microscope features an XY movement stage with 50 mm x 30 mm travel. You can guide your specimen using the control knobs to move the stage horizontally and vertically, ensuring precise positioning for examination.

Q: What benefits does the anti-fungal coated optics provide?

A: Anti-fungal coated optics help prevent fungal growth on lenses and optical parts, enhancing longevity and maintaining clear image quality even in humid environments. This is especially beneficial for extended use in labs or educational settings.

Q: When should I use the mirror or an external light source for illumination?

A: The mirror illumination is ideal for settings with ample ambient light, while the external light option, such as an LED illuminator, is recommended when natural or room light is insufficient for proper sample observation.

Q: Where is this microscope most suitable for use?

A: This robust microscope is well-suited for medical labs, educational institutions, clinics, and field research environments in India, thanks to its portable design, stable base, and flexible illumination options.

Q: What is the process for replacing spare parts on this microscope?

A: Spare parts like bulbs, eyepieces, and objectives are easily replaceable. Simply refer to the user manual for instructions and use compatible components to ensure optimal performance and longevity.

Q: How does the coaxial coarse and fine focusing system enhance usability?

A: The coaxial adjustment system allows users to make both broad and detailed focus changes smoothly, facilitating quick transitions between low and high magnification while maintaining image clarity.

Q: What are the magnification options and their typical applications?

A: This microscope offers three magnification settings: 40X, 100X, and 400X. 40X is used for surface observation, 100X for detailed tissue studies, and 400X for viewing finer cellular structures.
