Travelling Microscope

Price 6500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Travelling Microscope Specification

Focus System
Rack and pinion with fine vernier screw

Spare Parts
Eyepiece, objective lens, stage glass, vernier scale

Theory
Other

Drawtube
Single, graduated drawtube for fine adjustments

Resolution
Least count up to 0.01 mm

Interface
Manual, not digital

Focal Distance
Adjustable via focusing knobs

Magnification
Typically 10X to 15X optical magnification

Dimensions
Approx. 40 cm (L) x 15 cm (W) x 35 cm (H)

Focus Range
Provided by rack and pinion mechanism

Eyepieces
10X/15X standard Huygenian eyepiece

Eyepiece Tube
Monocular, inclined at 45 degrees

Coarse Adjustment Range
Provided by vertical screw movement

Working Stage
Polished brass/steel stage with glass plate

Image Format
Visual observation only, no digital imaging

View Head
Monocular head fixed to sliding carriage

Interpupillary Distance
Fixed (single eyepiece)

Objective Achromatic
Achromatic objective for color correction

Travelling Microscope Trade Information

Minimum Order Quantity
1 Piece

FOB Port
EXW

Supply Ability
1 Piece Per Day

Delivery Time
15 Days

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
standard packing

Main Domestic Market
All India

Certifications
iso ce

About Travelling Microscope

Travelling Microscope

Specification

For meeting the versatile requirements of our respected clients, we are engaged in manufacturing, supplying and exporting Travelling Microscope. Offered instrument is used for measuring length with resolution. It is equipped with a microscope at the top which can be easily adjusted by sliding the rails. Our manufactured Travelling Microscope is made in strict adherence with the international standards. These are checked on various parameters before delivery ensuring complete satisfaction of our customers.

Other Information

The microscope consists of a heavy cast iron base fitted with three levelling screws with the top machined over which slides a gun metal carriage.
The slide can be clamped at any position by means of a clamping screw.
Fine Adjustments for final reading is done with a micrometer screw.
A vertical slide operating in a similar way is fitted on the horizontal carriage.
The microscope with rack and pinion is fitted on the vertical or horizontal position of microscope.
Microscope tube is fitted with 10x Ramsden Eye Piece with cross line graticule & an Achromatic 2"or 3" focal length objective of high quality.
Travels 17 cms horizontally and 14 cms vertically.
Guaranteed accurate vernier reading 0.02 or 0.01 mm.
With swing out magnifier for reading vernier.
Packed in a sturdy wooden box

Specification

Color	White
Portable	Yes
Brand	standard steel
Model	TM01
Magnification	40x

Precision in Measurement

Benefitting from a graduated drawtube and vernier scale, this microscope allows users to make minute adjustments and attain measurements with a precision of 0.01 mm. The rack and pinion system, paired with a fine vernier screw, ensures both reliability and ease of control.

Flexible Optical System

Featuring interchangeable 10X and 15X Huygenian eyepieces and an achromatic objective, the microscope provides crisp and color-corrected views. The optical system is tailored for visual research, making it highly effective for scientific and educational applications.

Durable and Adaptive Design

Constructed with robust materials like polished brass or steel, the stage accommodates different specimen types and ensures longevity. The adjustable focal length and inclined monocular head offer ergonomic use, catering to detailed laboratory investigations.

FAQs of Travelling Microscope:

Q: How is fine measurement achieved with this Travelling Microscope?

A: The Travelling Microscope uses a single, graduated drawtube and a vernier scale, enabling precise readings up to 0.01 mm, making it ideal for scientific experiments requiring high accuracy.

Q: What is the process for adjusting magnification and focus?

A: To adjust magnification, select the desired Huygenian eyepiece (10X or 15X). Focus adjustments are made manually using the rack and pinion mechanism and fine vernier screw, offering both coarse and fine control.

Q: When is it most beneficial to use this microscope?

A: This microscope is most advantageous in laboratory settings where precise linear measurements, optical clarity, and manual adjustment are paramount, such as physics experiments or calibration tasks.

Q: Where can this microscope be used effectively?

A: It is suitable for schools, colleges, research laboratories, and industrial testing facilities across India, particularly where visual measurement and analysis are required.

Q: What are the main benefits of using an achromatic objective?

A: The achromatic objective reduces chromatic aberration, providing sharp, color-corrected images, crucial for accurate visual observation and measurement.

Q: How do I replace spare parts like the eyepiece or vernier scale?

A: Spare eyepieces, objective lenses, stage glass, or vernier scales can be replaced by following the manufacturers instructions or contacting the supplier for compatible parts and guidance.
